Cow dung fertilizer granulator making machine Price

Technical Parameters of Cow dung fertilizer granulator making machine:

Model Power

(kw)

 Capacity

(t/h)

 Rotate Speed

(r/min)

 Drum Size Granule Diameter

(mm)

 Dimension

(mm)

 Granulating Ratio Inlet Moisture
GTZJ-60 37 1-2 1450 Φ600*1800mm 3-5 4500*1500*1050 ＞95% 20%-40%
GTZJ-80 55 2-3 1450 Φ800*2400mm 3-5 4900*1700*1250 ＞95% 20%-40%
GTZJ-100 75 3-5 1450 Φ1000*3000mm 3-5 5300*1900*1400 ＞95% 20%-40%
GTZJ-120 90 6-8 1450 Φ1200*3000mm 3-5 5700*2100*1700 ＞95% 20%-40%
GTZJ-150 110 8-10 1450 Φ1500*3000mm 3-5 6200*2800*2000 ＞95% 20%-40%

Introduction of Cow dung fertilizer granulator making machine:

The Cow dung fertilizer granulator making machine developed by our GATA Factory has various specifications such as Φ600 and Φ800. It can also develop and produce other specifications of Cow dung fertilizer granulator making machine according to user requirements. The housing of the Cow dung fertilizer granulator making machine is made of thick, seamless steel tubing that is rugged and never deformed. Coupled with a solid base design, it makes it run more smoothly.

Cow dung fertilizer granulator making machine qualified granulation rate of more than 95%, adapt to a variety of different formulations, the compressive strength of organic fertilizer is higher than the disc granulator and drum granulator, the large ball rate is less than 15%, particles The size uniformity can be adjusted by the stepless speed regulation function of the machine according to the user’s requirements. Cow dung fertilizer granulator making machine is most suitable for direct granulation after organic fertilizer fermentation, saving drying process and greatly reducing manufacturing costs. Now this Cow dung fertilizer granulator making machine is popular among users.

How does the work of Cow dung fertilizer granulator making machine:

Cow dung fertilizer granulator making machine utilizes the mechanical stirring force of high-speed rotation and the aerodynamic force generated thereby to continuously mix, granulate, spheroidize and compact the fine powder material in the machine to achieve the purpose of granulation.

The particle shape is spherical, the particle size is generally between 3-5 mm, and the granulation rate is ≥95%. The particle diameter can be appropriately adjusted by the material mixing amount and the spindle rotation speed of the Cow dung fertilizer granulator making machine . Generally, the mixing amount is lower. The higher the rotational speed of the Cow dung fertilizer granulator making machine, the smaller the particles and vice versa.
