Animal Waste New type organic fertilizer Granulator Manfacturer

Animal Waste New type organic fertilizer Granulator

New Type Organic Fertilizer Granulator Capacity: 1-3 tons per hour. New Type Organic Fertilizer Granulator Raw materials: animal wastes, sludge, vinasse, bagasse and some other organic materials. New Type Organic Fertilizer Granulator Applicated range: organic fertilizer production. New Type Organic Fertilizer Granulator Advantage: large capacity, stable working, high granulating ratio, best granule surface

Get price Send us

Technical Parameter of New Type Organic Fertilizer Granulator

Model Power

(kw)

 Capacity

(t/h)

 Rotate Speed Drum Size (mm) Granule Diameter Dimension(mm) Granulate Ratio Angle Drum Rotate Speed
LAZM-60/120 37+7.5 1-3 1450r/min Φ1200*6000 3-5 mm 6600*1800*2000 ＞96% 2-2.5° 17 r/min


Introduction of New Type Organic Fertilizer Granulator

Animal Waste New type organic fertilizer Granulator is a molding machine which can make the material into specific shape. It is suitable for large production of cold, hot granule and high and low concentration compound fertilizers. New type organic fertilizer Granulator for sale can not only granulate a variety of organic matter, especially for the coarse fiber materials which are difficult to be granulated by conventional equipment, such as crop straw, wine residue, mushroom residue, drug residue, animal dung and so on. With the combination of the two granulating methods, it will make the granule forming rate more higher, and the granules are more beautiful, while saving energy and energy efficiency.

Features of New Type Organic Fertilizer Granulator

1. Mixing and rotating together, two granulating method combined for working in New type organic fertilizer Granulator for chicken manure

2. Special rubber sheet lining or acid resistant stainless steel liner can be added, better solve materials stick to the drum

3. Stable foundation, thickened spiral steel materials and ametabolic wheel will ensure machine stable working

4. Widely raw materials processing in Animal Manure New type organic fertilizer Granulator.

Working Principle of New Type Organic Fertilizer Granulator

Main work method of New type organic fertilizer Granulator manufacturer is aggregate wet granulation, through a certain amount of water or steam, the basic fertilizers that been wetted in the cylinder body will react; under a certain liquid conditions, with the rotation of the tube, the material particles are created to squeeze together the balls. Then high speed rotating mechanical shearing force and the resulting air power in Bio New type organic fertilizer Granulator will make continuous implementation of the fine powder material in the machine mixing, granulating, spheroidizing, density and other processes, which achieves the goal of the granulation.
